Deye Solar invertor In German Warehouse Nep 300w to 2000w Micro Inverter

Additional information

Input Voltage	25-55V
Output Voltage	176-242V
Output Current	2.7A
Output Frequency	50Hz/60Hz
Size	21.2234cm
Warranty	10YEARS

Product Information

Deye Micro Invertor

(Solar Invertor)

Higher yields / Safe & Reliable / Smart / User-friendly

Deye microinverters’ (Solar Invertor ) power ranges from 300W to 2000W, and it comes with different output voltage 220V/230V/127V. It supports multiple communication methods WIFI/PLC/Zigbee. Thanks to the MECD, communication gateway, the microinverter can be turned off remotely and immediately.

Compared with a string inverter, a microinverter can harvest the maximum power of each panel for the independent MPPT design. Also, it gives you module-level monitoring, making the O&M easier. Solution and service by Deye – a famous Microinverter Manufacturer. Solar Invertor

There are two general classifications of power optimizers: analog and digital. Typically, an analog optimizer uses a discrete control to regulate the output from the source. In a sense, it is similar to the microinverter discussed above. However, unlike the microinverter, it does not use any semiconductor logic to accomplish its task, instead relying solely on the electrical signals it senses from the input voltage. In this respect, it is distinct from a load regulator, which monitors and controls the maximum amount of energy drawn by the equipment. Solar Invertor .

Model	SUN300G3	SUN500G3	SUN600G3	SUN800G3	SUN1000G3	SUN1300G3	SUN1600G3	SUN2000G3
	US-220v	US-220v	US-220v	US-220v	US-220v	US-220v	US-220v	US-220v
	EU-230V	EU-230V	EU-230V	EU-230V	EU-230V	EU-230V	EU-230V	EU-230V
Input Data (DC)
Recommended input Power (STC)	210~400W (1 Piece)	210~600W (1 Piece)	210~400W (2 Pieces)	210~500W (2 Pieces)	210~600W (2 Pieces)	210~400W (4 Pieces)	210~500W (4 Pieces)	210~600W (4 Pieces)
Maximum input DC Voltage	60V
MPPT Voltage Range	25~55V
Full Load DC Voltage Range (V)	24.5~55V	40~55V	24.5~55V	33~55V	40~55V	26.5~55V	33~55V	40~55V
Max. DC Short Circuit Current	19.5A		2×19.5A			4×19.5A
Max. input Current	13A		2×13A			4×13A
No.of MPP Trackers	1		2			4
No.of Strings per MPP Tracker	1		1			1

Output Data (AC)
Model	SUN300G3		SUN500G3		SUN600G3		SUN800G3
	US	EU	US	EU	US	EU	US	EU
Rated output Power	300W		500W		600W		800W
Rated output current	1.4A	1.3A	2.3A	2.2A	2.7A	2.6A	3.6A	3.5A
Maximum units per branch	17		10		8		6
Model	SUN1000G3		SUN1300G3		SUN1600G3		SUN2000G3
	US	EU	US	EU	US	EU	US	EU
Rated output Power	1000W		1300W		1600W		2000W
Rated output current	4.5A	4.4A	5.9A	5.7A	7.3A	7A	9.1A	8.7A
Maximum units per branch	5		4		4		3
Nominal Voltage / Range(this may vary with grid standards)	220V/0.85Un-1.1Un	230V/0.85Un-1.1Un	220V/0.85Un-1.1Un	230V/0.85Un-1.1Un	220V/0.85Un-1.1Un	230V/0.85Un-1.1Un	220V/0.85Un-1.1Un	230V/0.85Un-1.1Un
Nominal Frequency / Range	50 / 60H
Extended Frequency/Range	45~55Hz / 55~65Hz
Power Factor	>0.99
Efficiency
CEC Weighted Efficiency	95%
Peak Inverter Efficiency	96.50%
Static MPPT Efficiency	99%
Night Time Power Consumption	50mW
Features
Compatibility	Compatible with 60~72 cell PV modules
Communication	Power line / WIFI / Zigbee
Grid Connection Standard	EN50549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116, RD1699, UNE 206006 IN, UNE 206007-1 IN, IEEE1547
Safety EMC / Standard	UL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3
Warranty	10 years

SUN300/500G3-US-220/EU-230 | 300-500W | Single Phase | 1 MPPT | Micro-Inverter (Solar Invertor) | Rapid Shutdown

The SUN 300-500G3 is a new generation grid-tied microinverter with a single MPPT, adapting to connect a 1pcs PV module. Thanks to the 1 MPP tracker design, ensuring that each PV module can harvest the highest power generation. Viewable panel performance on a PC, tablet, or smartphone.

* Module level monitoring, safer and smarter
* 1 unit for 1 panel, maximize energy from each panel
* Rapid shutdown function
* IP67 protection degree，10 years warranty
* PLC, Zigbee, or WIFI communication
* 1 MPP tracker, module-level monitoring

SUN600/800/1000G3-US-220/EU-230 |600-1000W| Single Phase | 2 MPPT | Micro-Inverter (Solar Inverter) | Rapid Shutdown

The SUN 600/800/1000G3 is a new-generation grid-tied microinverter with intelligent networking and monitoring systems to ensure maximum efficiency. The SUN 600/800/1000G3 is optimized to accommodate today’s high-output PV modules effectively with up to 500W output and dual MPPT. Also, it supports rapid shutdown applications, ensuring your investment is safe.

* Module level monitoring, safer and smarter
* Max. DC input current 13A, adapt to 500W PV module
* Rapid shutdown function
* IP67 protection degree，10 years warranty
* PLC, Zigbee, or WIFI communication
* 2 MPP trackers, module-level monitoring Solar Inverter

SUN1300-2000G3-US-220/EU-230 | 1300-2000W | Single Phase | 4 MPPT | Micro-Inverter (Solar Inverter) | Rapid Shutdown

The SUN 1300-2000G3 is a new-generation grid-tied microinverter with intelligent networking and monitoring systems to ensure maximum efficiency. High efficiency, and high reliability of the SUN 1300-2000G3 with 4 independent MPPT inputs, Maximum AC output power reaching 2000W. It comes with 2pcs AC cables, while in parallel, with great flexibility on the installation.

* Rapid shutdown function
* IP67 protection degree，10 years warranty
* Support reactive power communication
* 4 MPP trackers, module-level monitoring
* Max. DC input current of 13A, adapt to 600W PV module

Remotely shutdown function

Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely, which makes PV plant O&M easier.
