| Efficiency (Peak) PV to INV | 97% |
|---|---|
| Efficiency (Peak) Battery to INV | 94% |
| Transfer Time | 10 ms(For Personal Computers); |
| Output Port | Single output |
| Waveform | Pure sine wave |
| Battery Voltage | 24VDC |
● Pure sine wave inverter.
● Compatible to AC mains or generator power.
● Configurable AC/Solar input priority via LCD setting
● Cold start funcion.
● Overload / Over temperature/short circuit protection.
● Selectable input voltage range for home appliances and personel computers. Built-in MPPT solar controller.
● Auto restart while AC is recovering
● Status indication with RGB lights.
| Datasheet | PLUS 4000-24 | PLUS 6000-48 |
| Rated Power | 4000W | 6000W |
| Input | ||
| voltag | 230VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) |
|
| Frequency Range | 50HZ / 60HZ (Auto sensing) | |
| Output | ||
| AcvoltageRegulation(Batt .Mode) | 230VAC ± 5% | |
| Surge Power | 8000W | 12000W |
| Efciency (peak) PV to INV | 97% | |
| Efciency (peak) Battery to lNV | 94% | |
| Tranfer Time | 10 ms (For Personal Computers); 20 ms (For Home Appliances) |
|
| Output port | single output | |
| waveform | pure sine wave | |
| Battery & AC Charger | ||
| Battery Voltage | 24VDC | 48VDC |
| Floating charge voltage | 27VDC | 54VDC |
| Overcharge Protection | 33VDC | 61VDC |
| Maximum charge current | 100A (From grid) | |
| soc display | Shows battery State of charge in percentage and in voltage as well | |
| sleeping Mod | YES | |
| Battery voltage low cut off selectable | 21V-24V | 42v-49V |
| Battery High voltage range selectable | 25V-30V | 50V-60V |
| workswithoutBattery | YES | |
| Solar Charger | ||
| Maximum PV Array Power | 3500W | 6500W |
| MPPT Range @ Operating Voltage | 60～450VDC | |
| Maximum PV Array Open Circuit Voltage | 500VDC | |
| Maximum charging current | 120A | |
| Maximum Efficiency | 98% | |
| Physical | ||
| Dimension, D x W x H (mm) | 426*322*120 | |
| Net weight (kgs) | 8.7 | 10.6 |
| communication interface | RS485/ Wifi option (BMS Compatible with lithium battery using RS-485) | |
| LCD display | General LCD | |
| Operating Environment | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| OperatingTemperature | 0°C -55°C | |
| StorageTemperature | -15C -60°C | |
