High efficiency monocrystalline photovoltaic 290-300W Solar Panels for sale
High efficiency monocrystalline photovoltaic 290-300W Solar Panels for sale
Additional information
| Solar cell | A-grade |
|---|---|
| Connector | QC4 Compatible Connector |
Product Information
monocrystalline solar panels for sale Glass
* High-transmittance and low reflection * Inspection:GB15763.2-2005.ISO9050 * High solar transmittance * High mechanical strength * High flatness
monocrystalline solar panels for sale Cell
* High output-power: conversation efficiency is 18%-22% * High shunt-resistance: adapt the several environmental conditions. * Bypass diode minimizes the power drop by shade * Excellent low light effect * Low breakage rate
Frame
* Aluminium extrusion profile with prompt delivery * Available in customized surface finish * Excellent material for smooth and subtle edges * Extrusion for construction and other industrial purposes * Thickness variable according special request
Junction Box
* High current and voltage carrying capacity * Simple, quick and safe effective field assembly * IP 68 it can be used in the outdoor iron environment * Expansion connector are available for future requirement * Double permanent connection are adapted for all of the connecting.
|
Module
|
TTN 290W
|
TTN 295W
|
TTN 300W
|
|
Peak Power Watts(Pmax/W)
|
290
|
295
|
300
|
|
Power Output Tolerance(W)
|
0~+5
|
||
|
Maximum Power Voltage(Vmp/V)
|
31.98
|
32.25
|
32.54
|
|
Maximum Power Current(Imp/A)
|
9.07
|
9.15
|
9.22
|
|
Open Circuit Voltage(Voc/V)
|
46.22
|
46.22
|
46.22
|
|
Short Circuit Current(Isc/A)
|
9.46
|
9.52
|
9.61
|
|
Module Efficiency(%)
|
17.82
|
18.13
|
18.44
|
|
STC:Irradiance 1000W/m2,Cell Temperature 25°C,Air Mass AM1.5.
*Measuring Tolerance: ±3%. |
|||
